Moose lite 3D Scanner

Moose lite 3D Scanner

$279.00
Model
Combine

Introducing 3DMakerpro Moose Series

Moose is more than just a high-precision scanner; it’s a smarter solution for scanning. With the power of advanced AI tracking and an innovative point cloud algorithm, Moose will elevate both your scanning efficiency and quality to new heights.

Intelligent Pre and Post Data Processing

JMStudio scanning software integrates scanning, editing, and optimizing into one seamless process.

The Moose series is equipped with a new generation of single-frame encoded structured light units that improve surface feature detection for smooth, marker-free scanning.

AI Visual Tracking

AI eliminates flawed or misaligned point cloud data while retaining accurate points.
Smart Error Correction

Tech Specs

JMStudio can automatically stitch in most scenarios ensuring seamless connections.

Auto Align

With 0.10mm resolution³

Detailed point clouds perfectly preserve object details providing refined models for printing or display projects.

Up to 100mm Scan Depth⁴

Enhanced depth exploration significantly improves vertical scanning capabilities covering complex models comprehensively even those with intricate structures.


Scan Performance Parameters:

  • Accuracy: 0.05mm
  • Resolution: 0.10mm
  • Frame rate: 10fps
  • Tracking mode: AI Visual tracking
  • Work distance: 150-400mm
  • Single capture range: 200x100mm
  • Typical object sizes: 15-1500mm
  • Surface Treatment Recommendations: Certain surfaces and materials, such as transparent, reflective, or those hairy area may require a scanning spray for optimal scanning results.

Hardware Parameters:

  • Light source: NIR
  • Color texture: Mono color textures
  • USB interface: USB2.0
  • Dimensions: 115×70×35mm
  • Weight: 250g


Software System Requirements:

  • Output format: OBJ/STL/PLY/ASC
  • Compatible system: Windows10/11 64bit, MacOS12/13/14
  • Compatible mobile: Android 10.0 or later, iOS 15.0 or later (Extended support)
  • Minimum computer requirements: Intel Core i5 8th, 16GB RAM MX250 GPU with 2GB VRAM
  • Recommended computer requirements: Intel Core i7 8th, 16GB RAMNVDIA 3060 GPU with 4GB VRAM
